Green WP Pure Tungsten Electrode 4.8mm Diameter

Products

Stainless Steel Flux Cored Wire

Green WP Pure Tungsten Electrode 4.8mm Diameter

MOQ:	1080 kilograms
Standard Packaging:	10pcs/ Plastic Box

Detail Information

Product Description

Detail Information

Place of Origin

Shandong, China

Brand Name

CHENXIANG

Model Number

WP Pure Tungsten Electrode

Warranty:

2 Years

Customized Support:

OEM, ODM, OBM

Material:

Tungsten

Diameter:

1.0/1.6/2.0/2.4/3.0/3.2/4.0/4.8mm

Color:

Green

Packing:

10pcs/ Plastic Box

Application:

TIG Welding

Welding Type:

Argon Arc Welding

Surface:

Ground

Delivery Time:

5 Days

Usages:

Aluminum, Magnesium Alloy

Advantage:

Low Resistance, Good Conductivity, Small Thermal Expansion

Length:

150mm/175mm

Welding Current:

International Standard

Highlight:

WP Pure Tungsten Electrode

Green Pure Tungsten Electrode

4.8mm Pure Tungsten Electrode

Product Description

Green WP Pure Tungsten Electrode 4.8mm Diameter

Green WP Pure Tungsten Electrode 4.8mm Diameter 0

Product Description

WP tungsten electrode (pure tungsten electrode) is an electrode with a tungsten content of more than 99.9%, usually green in color. Its main component is pure tungsten, which has high melting and boiling points, is not easy to melt and volatilize, and has less tip contamination. The WP tungsten electrode has a high electron work function, which makes it difficult to start the arc and the arc stability is average, but it performs well in AC welding, especially for welding aluminum and magnesium alloys.

Features:
High melting and boiling points: WP tungsten electrodes have extremely high melting and boiling points and can remain stable at high temperatures.

Not easy to melt and volatilize: Due to its high melting and boiling points, the electrode is not easy to melt and volatilize during use.

Less tip contamination: Less contamination at the tip of the electrode helps maintain welding quality.

Difficult to start the arc: Due to the high electron work function, it is difficult to start the arc and the arc stability is average.

Details Images

Model	WP
Diameter	1.0/1.6/2.0/2.4/3.0/3.2/4.0/4.8mm
Length	150mm/175mm

Green WP Pure Tungsten Electrode 4.8mm Diameter 1

Specifications

Model	Electrode Name	Added Impurity	lmpurity Quantity(%)	Other Impurities(%)	Tungsten(%)	Color Sign
WP	Pure Tungsten Electrode	——
